Includes:
- G4529A Main Frame
- G8130A Sample Tray
- G4513A Tower
- 6x 50-vial trays
The Agilent 7696A Sample Prep WorkBench provides consistent precision and eliminates errors associated with mundane sample preparation procedures, such as dilutions, internal standard additions, and derivatization. WorkBench with WeighStation provides the ability to weigh precise amounts of material directly into the GC or LC vial, allowing for weight calculations required for specific ASTM and EN methods. The 7696A Sample Prep Workbench is a standalone instrument, it is designed to operate in safe fume hood environment. It is compatible with any vendors LC, GC,LC/MS and GC/MS.
Specifications
| Type | Specifications |
|---|---|
| Variable sampling depth | –2 to +30 mm above default |
| Pre- and post-liquid syringe | 0–15 rinses for each of solvent A and B rinsing |
| Sample prewashes | 0–15 prewashes |
| Viscosity delay | 0–7 seconds |
| Solvent saver | Set at 10, 20, 30, 40, and 80% of syringe volume |
| Syringe size | 1-, 2-, 5-, 10-, 25-, 50-, and 100-μL maximum volume with standard syringe carriage 250- and 500-μL maximum volume with optional enhanced sample handling syringe carriage |
