This refurbished Agilent G1364D Micro Fraction Collector is in great condition. It has been tested at SpectraLab Scientific. A 90-day warranty is included.
| Delay volume: | • 0.25 µL with 25 µm capillary (typically)
• 1 µL with 50 µm capillary • 4 µL with 100 µm capillary |
| Fraction containers: | 384 and 96 well-plate format (standard and conical shape),
• Eppendorf safe-lock tubes (0.5, 1.5, 2.0 mL) |
| MALDI carriers: | For Agilent, Applied Biosystems, Bruker and Micromass targets |
| Fraction capacity: | 4 well-plates, 4 MALDI plates or 4 x 27 Eppendorf tubes |
| Maximum collector capacity: | 2 micro fraction collectors/spotters in parallel
with 2-position/6-port micro valve |
| Typical volumes for spotting: | 100 – 5000 Nl |
| Spot frequency: | < 0.33 (Hz) |
| Matrix addition: | With syringe pump |
| Maximum system flow: | 100 µL/min (higher flow rates requires system modifications) |
| Minimum fraction volumes: | Typically 2 µL (depending on fraction collection container) |
| Cooling: | Optional |
| Trigger modes: | Time and peak-based (threshold, up-/downslope, upper threshold
and timetable), combination of different modes |
| Trigger source: | Agilent 1200 Series MWD and DAD detectors,
third-party detectors (require UIB) |
| Environment: | 4 – 55 °C constant temperature, < 95% humidity (non-condensing) |
